What safety devices are usually equipped in mechanical parking spaces

Release time：2021-03-01

、

1. Warning device in operation

When the mechanical parking space is in operation, warning lights, buzzers, and other devices will be activated. The warning lights should remain flashing until the carrier board reaches its position, serving the purpose of warning personnel and vehicles to pay attention to safety. In case of an emergency, the emergency button can be pressed, and the buzzer will be activated until the situation is resolved before stopping sounding.

2. Emergency stop button device

If there is an emergency or someone accidentally enters the action area of the mechanical parking space when using it to park or pick up the car, the emergency stop button device can be used to ensure safety, and the mechanical parking space will stop all actions. In general, the emergency stop button device is located in the operation box and is highlighted in red for easy access and use during operation.

3. PLC interlock and limit prevention device

During the operation of the mechanical parking space, a PLC interlocking device is required to prevent overlap or collision between the lifting and lateral loading plates. This device can set the interlocking positioning points for the lifting and lateral movement of the mechanical parking space to prevent collision accidents. In addition, mechanical parking spaces also have limit prevention devices to prevent damage to equipment or vehicles caused by exceeding the limit during the lateral movement of the loading plate.
